Find answers to your questions about our innovative electric outboards and propulsion systems. Explore topics from performance to technical specs and discover how ACEL Power is steering the marine industry.
KWH stands for kilowatt-hour, a unit of energy storage capacity in batteries.
KW stands for kilowatt, a unit of power measurement.
To convert horsepower to kilowatts, multiply the horsepower value by 0.746.
Example: 1 electrical horsepower = 0.746 KW
Torque refers to the rotational force or twisting force generated by an engine or motor. In the context of marine propulsion, torque determines the engine’s ability to rotate the propeller and move the boat through the water. A higher torque value means that the engine can exert more force to turn the propeller, resulting in improved acceleration, especially at lower speeds. It’s a critical factor in achieving efficient and responsive movement, especially during planning and acceleration phases. The common unit for torque is N*m (newton times meter) in metric and foot-pounds in imperial.
RPM stands for “Revolutions Per Minute.” In the context of marine propulsion, RPM refers to the number of complete rotations a boat’s engine or motor makes in one minute. It’s a measure of how fast the engine’s crankshaft is turning and is a critical factor in determining the speed and performance of the boat.
For marine propulsion, RPM is used to indicate how many times the propeller attached to the engine’s output shaft completes a full rotation in a minute. The RPM value is closely linked to the power and torque of the engine and influences the boat’s acceleration, top speed, and overall efficiency. Properly managing RPM is important for achieving optimal performance, fuel efficiency, and safe operation of the vessel.
Planing in boating refers to the phenomenon where a boat rises and travels on the surface of the water, rather than pushing through it. When a boat is planing, it essentially skims the water’s surface, supported by hydrodynamic forces, and achieves a higher speed and improved efficiency. Planing is typically achieved by increasing the boat’s speed and can happen faster when using our electric motors which have 30% more torque over fuel-based propulsion.
Outboard motors offer several advantages over inboard motors. They are typically more versatile and easier to maneuver, thanks to their external mounting on the transom of a boat, allowing for quicker directional changes and improved handling. Outboards are generally easier to access for maintenance and repair, as they can be easily lifted out of the water and removed. They also save valuable space within the boat, making them more suitable for smaller watercraft.
Electric outboard motors are versatile and can be used in a variety of water bodies, including both saltwater and freshwater environments. Electric outboards can perform well in saltwater conditions. However, one challenge in saltwater environments is the potential for corrosion. Regular maintenance, such as rinsing the motor with freshwater after each use and using anti-corrosion coatings, is essential to mitigate the effects of saltwater and ensure the longevity of the outboard. ACEL motors are equipped with N-nodes, which help prevent corrosion and enhance the longevity of the system in all environments.
ACEL Power is a clean tech company that designs and manufactures electric motors for the marine industry. ACEL’s commitment to shaping a sustainable future is realized through its state-of-the-art products, setting new standards for performance, maintenance, and longevity in marine propulsion. Leveraging patented technology and integrated software solutions, ACEL Power aims to revolutionize the marine industry, driving change towards cleaner, more efficient boating experience.
ACEL Power is a Canadian company led by CEO and Co-founder Anthony Liu. With roots in decades of manufacturing experience and a history of serving Fortune 500 companies, ACEL team has a strong foundation in clean energy innovation. Launched in 2021, the company is focused on revolutionizing marine propulsion by designing intelligent electric propulsion systems that deliver high performance, low maintenance, and zero emissions—paving the way for a more sustainable future on the water.
Currently, ACEL Power is developing a new hybrid electric and hydrogen fuel cell marine propulsion system for the Indian Ministry of Defence in collaboration with Tata Motors. This innovative project represents a significant step forward in the use of hydrogen fuel cell technology for sustainable and efficient marine transportation solutions.
By developing this technology, we can encourage clean energy adoption, reduce emissions, encourage sustainable government policy and transfer clean energy propulsion to more types of transportation.
At ACEL Power, we’re committed to continuous innovation and enhancing our electric propulsion systems to meet the evolving needs of our customers and the marine industry. Some of the exciting innovations we’re actively working on include: lighter batteries, V2L (Vehicle-to-Load) technology, low balancing solutions; and software control improvements.
We are launching 150HP and 250HP, followed by other higher and lower HP. As well we are expanding features on our software that include autonomous and IOT features like assisted docking, anti-theft, etc.
Our flagship product is the ACEL Intelligent Electric Series, available in 50HP and 75HP models, with 150HP and 250HP versions available for pre-order. This all-in-one electric propulsion system includes the motor, modular battery system, digital throttle, smart charger, smart key, and onboard computer with touchscreen controls. We also offer the ACEL X-Tend, a portable gas-powered range extender for longer trips or hybrid applications.
The electric outboard propulsion system consists of several key components that work together to generate and control power. These components include:
ACEL Power offers a comprehensive, technologically advanced, and reliable solution for electric outboard motors, backed by certifications and features that ensure superior performance, safety, and peace of mind.
The display is designed to be versatile and adaptable to various settings. It is both flush mount and stand-alone, providing flexibility in installation options. Importantly, the display is rated IP67, which means it has a high waterproof rating in case you accidentally drop it in the water.
As for the charger, it’s a portable smart charger that you connect directly to the electrical grid using a standard wall socket. This connection to the grid ensures a stable and reliable source of power for charging.
Yes. While currently, our system allows for programming one engine to one throttle, we are actively working on expanding our offerings to provide you with more options in the future.
The propeller included with your system is designed to work well with your ACEL Power electric motor under normal operating conditions making it a convenient and hassle-free choice for most users.
However, if you have specific preferences or requirements, or if you ever need to replace a propeller, you have the flexibility to choose from a range of options. Keep in mind that the choice of propeller can impact the performance and efficiency of your electric motor, so it’s a good idea to consult the user manual or reach out to ACEL Power’s customer support for guidance if you’re unsure about which propeller to select for your particular boating needs.
Yes, ACEL Power electric motors are designed with water safety in mind. They are rated IP67, which means they are water-resistant. This level of protection ensures that our electric motors can withstand exposure to various environmental conditions, making them ideal for marine applications where water contact is likely to occur.
At ACEL Power, we are constantly exploring innovations to enhance the boating experience for our customers. While our system currently requires a steering wheel for control, we are actively considering the integration of joystick control systems in our future product lineup. Our commitment to providing the best possible boating experience means that we are open to integrating new technologies that can improve your time on the water.
Yes, over the years, owners of ACEL Power electric propulsion systems experience increasing cost savings when compared to traditional fuel-powered systems. The key contributors to these savings are lower fuel and maintenance costs. As the motor ages, the savings increase as maintenance costs related to gas motors significantly increase.
The shaft is the part of the outboard from the top of the clamp bracket to the bottom of the cavitation plate (for combustion outboards) or central of the propeller (for electric outboards). Standard/ short shaft is 15”, long shaft is 20”, extra long is 25” and ultralong is 30”. We provide a 20” shaft by default and can provide up to 35” shaft through custom request, in 5” increments.
ACEL is currently mass producing 2 models IE 50 and IE 75 and available immediately. We are also taking pre-orders for 150HP and 250HP with a lead time of 12-14 weeks.
Please contact our sales team at info@acelpower.com
The weight aligns with the standard industry practice. Notably, ACEL batteries are five times lighter than regular car batteries.
The battery is stored inside the boat, strategically placed closer to the centre of gravity, and designed based on the boat’s specifications.
The placement of the battery impacts weight distribution and planing. It is very important to manage the centre of gravity to balance the weight distribution. Correct battery placement enhances planing performance.
The battery is made of lithium iron phosphate (LFP), a highly stable and safe lithium-ion chemistry. LFP batteries offer superior thermal stability, minimizing the risk of overheating or fire. This makes them a reliable choice for marine applications.
Connecting the battery is straightforward. Match the red terminal to red (+ve) and the black terminal to black (-ve). Our battery installation process is designed to be user-friendly.
To charge in such scenarios, you’ll need either a portable charge pack or a portable fuel-fired generator. ACEL X-Tend is a compact gas generator designed to seamlessly recharge your battery system when shore power or solar options aren’t available, ensuring extended range and uninterrupted operation even in remote locations.
The boat may stop, but the software continues running, allowing you to contact SOS if needed. As the battery charge diminishes, the power output gradually decreases. When the charge level reaches 30%, the power output is reduced by a certain percentage; at 20%, it’s reduced by another value, and at 10%, yet another value. This stepwise reduction strategy aims to lower the likelihood of depleting the battery completely before safely returning to the marina.
Regular maintenance is an important part of ensuring the longevity and reliability of your ACEL Power system. While the specific requirements may vary based on usage and environmental conditions, typical annual maintenance tasks include:
For specific maintenance instructions and intervals, we recommend referring to the service manual provided with your ACEL Power system.
Saltwater exposure can have a corrosive effect on boat motors. When saltwater comes into contact with metal components of the motor, it can lead to the formation of rust and corrosion, which can significantly impact the motor’s performance and longevity.
ACEL Power motors are equipped with N-nodes which mitigate the effects of corrosion when operating in saltwater environments. They act as a protective barrier, reducing the risk of damage to the motor. This helps to prolong the lifespan of the motor and maintain its efficiency.
If you encounter a software malfunction in your electric outboard propulsion system, you can take the following steps to address the issue:
The electric outboard motor typically does not need to be replaced unless it has sustained irreparable damages. Electric outboard motors are designed to be durable and have a long lifespan, and their longevity largely depends on how well they are maintained and used. Regular maintenance, such as cleaning, lubrication, and inspections, can help prolong the motor’s life.
Our warranty coverage is as follows:
It’s important to note that consumable parts such as gear oil are not covered by our warranty. We stand by the quality and durability of our products and are committed to supporting your investment in our technology. If you have any specific warranty-related questions or need further assistance, please don’t hesitate to reach out to our customer support team.
Your nearest ACEL Power dealer will be able to provide service and maintenance for your unit. We have a network of authorized dealers who are trained and equipped to handle the servicing needs of our units. They will be your go-to resource for any maintenance, repairs, or service inquiries you may have. Our dedicated dealers are committed to ensuring that your ACEL Power unit operates at its best, so you can enjoy your boating experience to the fullest.
On average, electric motors can last up to 10 times longer than their gas counterparts. Electric motors have fewer moving parts, which means there is less wear and tear over time. They also generate less heat and vibration during operation, further reducing the stress on components. ACEL Power electric motors are an exceptionally reliable choice for various applications, including water taxis and other marine uses, where durability and consistent performance are paramount.
KWH stands for kilowatt-hour, a unit of energy storage capacity in batteries.
KW stands for kilowatt, a unit of power measurement.
To convert horsepower to kilowatts, multiply the horsepower value by 0.746.
Example: 1 electrical horsepower = 0.746 KW
Torque refers to the rotational force or twisting force generated by an engine or motor. In the context of marine propulsion, torque determines the engine’s ability to rotate the propeller and move the boat through the water. A higher torque value means that the engine can exert more force to turn the propeller, resulting in improved acceleration, especially at lower speeds. It’s a critical factor in achieving efficient and responsive movement, especially during planning and acceleration phases. The common unit for torque is N*m (newton times meter) in metric and foot-pounds in imperial.
Typically, travel range is quantified in distance, not time. The 50HP (32 kWh) battery pack offers a range of about 50 kilometres, while the 75HP (40 kWh) pack allows for approximately 200 kilometres at a speed of 5 knots. Yes, with Acel motors range anxiety is a myth.
Planing in boating refers to the phenomenon where a boat rises and travels on the surface of the water, rather than pushing through it. When a boat is planing, it essentially skims the water’s surface, supported by hydrodynamic forces, and achieves a higher speed and improved efficiency. Planing is typically achieved by increasing the boat’s speed and can happen faster when using our electric motors which have 30% more torque over fuel-based propulsion.
Typically, travel range is quantified in distance, not time. The 50HP (32 kWh) battery pack offers a range of about 50 kilometres, while the 75HP (40 kWh) pack allows for approximately 200 kilometres at a speed of 5 knots. Yes, with Acel motors range anxiety is a myth.
Electric outboard motors are versatile and can be used in a variety of water bodies, including both saltwater and freshwater environments. However, it’s important to note the difference between saltwater and freshwater usage:
Saltwater: Electric outboards can perform well in saltwater conditions. However, one challenge in saltwater environments is the potential for corrosion. Regular maintenance, such as rinsing the motor with freshwater after each use and using anti-corrosion coatings, is essential to mitigate the effects of saltwater and ensure the longevity of the outboard. Acel Motors agave N-nodes which prevent corrosion.
Freshwater: Freshwater usage is generally less challenging for ACEL Power electric outboards in terms of corrosion. These motors typically require minimal maintenance when used in freshwater environments.
The shaft is the part of the outboard from the top of the clamp bracket to the bottom of the cavitation plate (for combustion outboards) or central of the propeller (for electric outboards). Standard/ short shaft is 15”, long shaft is 20”, extra long is 25” and ultralong is 30”. We provide a 20” shaft by default and can provide up to 35” shaft through custom request, in 5” increments.
There are various boat types including speed boats, pontoons, displacement hulls, sailboats, barges, and semi-displacement hulls.
ACEL Power is a clean tech company that designs and manufactures electric outboard motors for the marine industry. ACEL’s commitment to shaping a sustainable future is realized through its state-of-the-art products, setting new standards for performance, maintenance, convenience, and longevity in marine propulsion. Leveraging patented technology and integrated software solutions, ACEL Power aims to revolutionize the marine industry, driving change towards cleaner, more efficient boating experience.
ACEL Power is a Canadian company led by co-founders Anthony Liu, CEO, and John Liu, President. Michael Liu presides over the company as the Chairman. Michael was an early pioneer in the field of lithium-ion batteries establishing one of the first manufacturing companies in 1994. Acel Power is built on the experience of decades of manufacturing experience serving Fortune 500 companies and foundational patents developed by Michael in his pursuit of developing alternative energy solutions.
Hydrogen fuel cells are clean energy devices that convert hydrogen and oxygen into electricity, with water as the only byproduct. They operate through an electrochemical process, where hydrogen is split into protons and electrons, with the electrons creating an electric current that can be harnessed for power. Fuel cells are highly efficient, emit no harmful pollutants, and are increasingly being used in various applications, from powering vehicles to providing backup power for industries and homes, as they offer a sustainable and environmentally friendly alternative to conventional combustion-based energy sources.
Currently, ACEL Power is developing a new hybrid electric and hydrogen fuel cell marine propulsion system for the Indian Ministry of Defence in collaboration with Tata Motors. This innovative project represents a significant step forward in the use of hydrogen fuel cell technology for sustainable and efficient marine transportation solutions.
By developing this technology, we can encourage clean energy adoption, reduce emissions, encourage sustainable government policy and transfer clean energy propulsion to more types of transportation.
ACEL is currently mass producing 50HP and 75HP and are available with a 6-week lead time. We are also taking pre-orders for 150HP and 250HP which will be available early Q1 2024.
Please contact our sales team at stephen.p@acelpower.com
No, we do not have a floor plan in place right now. However, we are actively developing plans to offer this service. Dealers will manage inventory and make payments once items are sold.
At ACEL Power, we’re committed to continuous innovation and enhancing our electric propulsion systems to meet the evolving needs of our customers and the marine industry. Some of the exciting innovations we’re actively working on include: lighter batteries, V2L (Vehicle-to-Load) technology, low balancing solutions; and software control improvements.
Starting Q1 2024, we are launching 150HP and 250HP, followed by other higher and lower HP. As well we are expanding features on our software that include autonomous and IOT features like self parking, automated docking, etc.
The ideal boats for these electric motors are within the size range of 15 to 21 feet. These motors are versatile and can be used with various boat materials such as aluminium, fiberglass, or carbon fibre. They are compatible with different boat styles, including pontoon, fishing, skiff, and rigid inflatable boats (RIBs), encompassing a wide range of vessel types.
There are various boat types that can use an ACEL Power electric outboard system including speed boats, pontoons, displacement hulls, sailboats, barges, and semi-displacement hulls. Our electric propulsion system is a versatile and eco-friendly solution that can be adapted to a wide range of applications including pleasurecraft, commercial and defence. Our engineers work with your team to customize to meet your requirements. Contact us to discuss your boat type in more detail.
The electric outboard propulsion system consists of several key components that work together to generate and control power. These components typically include:
ACEL Power offers a comprehensive, technologically advanced, and reliable solution for electric outboard motors, backed by certifications and features that ensure superior performance, safety, and peace of mind.
The display is designed to be versatile and adaptable to various settings. It is both flush mount and stand-alone, providing flexibility in installation options. Importantly, the display is rated IP67, which means it has a high waterproof rating in case you accidentally drop it in the water.
As for the charger, it’s a land-based unit that you connect directly to the electrical grid using a standard wall socket. This connection to the grid ensures a stable and reliable source of power for charging.
Yes. While currently, our system allows for programming one engine to one throttle, we are actively working on expanding our offerings to provide you with more options in the future.
The propeller included with your system is designed to work well with your ACEL Power electric motor under normal operating conditions making it a convenient and hassle-free choice for most users.
However, if you have specific preferences or requirements, or if you ever need to replace a propeller, you have the flexibility to choose from a range of options. ACEL Power electric motors are compatible with Yamaha-spec propellers, which provides you with a wide selection to choose from. You can easily swap out the propeller with a Yamaha model that suits your needs or application.
Keep in mind that the choice of propeller can impact the performance and efficiency of your electric motor, so it’s a good idea to consult the user manual or reach out to ACEL Power’s customer support for guidance if you’re unsure about which propeller to select for your particular boating needs.
Yes, ACEL Power electric motors are designed with water safety in mind. They are rated IP67, which means they are not only water-resistant but also suitable for submersion in water for a certain period. This level of protection ensures that our electric motors can withstand exposure to various environmental conditions, making them ideal for marine applications where water contact is likely to occur.
At ACEL Power, we are constantly exploring innovations to enhance the boating experience for our customers. While our system currently requires a steering wheel for control, we are actively considering the integration of joystick control systems in our future product lineup. Our commitment to providing the best possible boating experience means that we are open to integrating new technologies that can improve your time on the water.
Yes, over the years, owners of ACEL Power electric propulsion systems experience increasing cost savings when compared to traditional fuel-powered systems. The key contributors to these savings are lower fuel and maintenance costs. Owners can typically save around $9,940 over five years based on normal usage. As the motor ages, the savings increase as maintenance costs related to gas motors significantly increase.
The battery sizes are as follows:
The weight of the battery varies:
The weight aligns with the standard industry practice. Notably, ACEL batteries are five times lighter than regular car batteries.
There are approximately 100+ cells in a battery module.
The battery is stored inside the boat, strategically placed closer to the centre of gravity, and designed based on the boat’s specifications.
The placement of the battery impacts weight distribution and planing. Correct battery placement enhances planing performance.
The battery is made of lithium iron phosphate (LFP), a highly stable and safe lithium-ion chemistry. LFP batteries, while slightly heavier than other types, offer superior thermal stability, minimizing the risk of overheating or fire. This makes them a reliable choice for marine applications compared to chemistries like lithium nickel manganese cobalt oxide (NMC).
The battery’s lifespan is approximately 3000 charge cycles. For individuals using the boat for leisure in marine settings, a single charge can provide around 2 hours of boat runtime. Typically, this results in approximately 50 cycles per year.
When using ACEL electric chargers, you’ll benefit from their intelligent design, enabling rapid charging within an hour. Wall chargers may require approximately 18 hours to achieve a full charge.
The battery should be stored within the temperature range of 15-55 degrees Celsius. ACEL’s batteries feature a proprietary in-built heating system that activates during charging. This system helps maintain temperatures above 15 degrees, particularly in colder conditions.
The battery becomes unsafe when exposed to temperatures under 15 degrees or over 55 degrees Celsius. ACEL’s batteries include a proprietary in-built heating system to manage temperature extremes.
Connecting the battery is straightforward. Match the red terminal to red (+ve) and the black terminal to black (-ve). Our battery installation process is designed to be user-friendly.
Typically, travel range is quantified in distance, not time. The 50HP (32 kWh) battery pack offers a range of about 50 kilometres, while the 75HP (40 kWh) pack allows for approximately 200 kilometres at a speed of 5 knots. Yes, with Acel motors range anxiety is a myth.
Typically, travel range is quantified in distance, not time. The 50HP (32 kWh) battery pack offers a range of about 50 kilometres, while the 75HP (40 kWh) pack allows for approximately 200 kilometres at a speed of 5 knots. Yes, with Acel motors range anxiety is a myth.
Typically, travel range is quantified in distance, not time. The 50HP (32 kWh) battery pack offers a range of about 50 kilometres, while the 75HP (40 kWh) pack allows for approximately 200 kilometres at a speed of 5 knots. Yes, with Acel motors range anxiety is a myth.
Typically, travel range is quantified in distance, not time. The 50HP (32 kWh) battery pack offers a range of about 50 kilometres, while the 75HP (40 kWh) pack allows for approximately 200 kilometres at a speed of 5 knots. Yes, with Acel motors range anxiety is a myth.
Typically, travel range is quantified in distance, not time. The 50HP (32 kWh) battery pack offers a range of about 50 kilometres, while the 75HP (40 kWh) pack allows for approximately 200 kilometres at a speed of 5 knots. Yes, with Acel motors range anxiety is a myth.
To charge in such scenarios, you’ll need either a portable charge pack or a portable fuel-fired generator. ACEL Power is working on developing portable power cubes that can be used to charge the battery wherever you are.
The boat may stop, but the software continues running, allowing you to contact SOS if needed. As the battery charge diminishes, the power output gradually decreases. When the charge level reaches 30%, the power output is reduced by a certain percentage; at 20%, it’s reduced by another value, and at 10%, yet another value. This stepwise reduction strategy aims to lower the likelihood of depleting the battery completely before safely returning to the marina.
Typically, travel range is quantified in distance, not time. The 50HP (32 kWh) battery pack offers a range of about 50 kilometers , while the 75HP (40 kWh) pack allows for approximately 200 kilometers at a speed of 5 knots. Yes, with Acel motors range anxiety is a myth.
When it comes to speed, electric motors exhibit a similarity to gas motors. However, a significant differentiating factor is torque. Electric motors provide an advantage in terms of torque, delivering around 30% more torque than traditional gas or diesel engines. This increased torque plays a vital role in propelling the boat efficiently and effectively, contributing to an enhanced overall performance.
Both the 50HP and 75HP electric motors have a power output of approximately 37kW. Their maximum RPM is around 7000.
Electric outboard motors generally require less maintenance compared to traditional fuel-powered motors, because they have fewer moving parts. Simple maintenance such as cleaning, lubrication and inspection is required. Refer to the maintenance schedule outlined in your owner’s manual for your specific electric propulsion system.
Saltwater exposure can have a corrosive effect on boat motors. When saltwater comes into contact with metal components of the motor, it can lead to the formation of rust and corrosion, which can significantly impact the motor’s performance and longevity.
ACEL Power motors are equipped with N-nodes which mitigate the effects of corrosion when operating in saltwater environments. They act as a protective barrier, reducing the risk of damage to the motor. This helps to prolong the lifespan of the motor and maintain its efficiency.
If you encounter a software malfunction in your electric outboard propulsion system, you can take the following steps to address the issue:
The electric outboard motor typically does not need to be replaced unless it has sustained irreparable damages. Electric outboard motors are designed to be durable and have a long lifespan, and their longevity largely depends on how well they are maintained and used. Regular maintenance, such as cleaning, lubrication, and inspections, can help prolong the motor’s life. Contact ACEL Power for more information about repairs and servicing. Check our warranty section for more information.
Our warranty coverage is as follows:
It’s important to note that consumable parts such as gear oil are not covered by our warranty. We stand by the quality and durability of our products and are committed to supporting your investment in our technology. If you have any specific warranty-related questions or need further assistance, please don’t hesitate to reach out to our customer support team.
Your nearest ACEL Power dealer will be able to provide service and maintenance for your unit. We have a network of authorized dealers who are trained and equipped to handle the servicing needs of our units. They will be your go-to resource for any maintenance, repairs, or service inquiries you may have. Our dedicated dealers are committed to ensuring that your ACEL Power unit operates at its best, so you can enjoy your boating experience to the fullest.
On average, ACEL Power electric motors can last up to 10 times longer than their gas counterparts. Electric motors have fewer moving parts, which means there is less wear and tear over time. They also generate less heat and vibration during operation, further reducing the stress on components. As a result, ACEL Power electric motors are an exceptionally reliable choice for various applications, including water taxis and other marine uses, where durability and consistent performance are paramount.
